R200

Categories: Cesab, Forklift trucks, New, Reach Trucks, Warehouse Trucks Tag: 4-wheel electric trucks

The CESAB R200 is a compact and flexible reach truck. With its narrow designed chassis it is ideal for stacking in narrow and constrained spots. The R200 offers high drive and lift speeds linked to optimal comfort for the driver

The driver is at ease with the simple and logical fingertip controls placed on the ergonomic console with integrated wrist rest. The electric steering allows effortless safe and precise manoeuvring.

Description

Description

R212

R214

R216

R212

Model

R212

Capacity

1200kg/600mm

Operator:

Ride-on

Mast Type:

DT / DF / TF

Lift height:

3350mm

Max lift height:

6000mm

Travel speed loaded/unloaded:

10/11 km/h

Lifting speed loaded/unloaded:

0.29/0.42 m/s

Lowering speed with/without load:

0.47/0.47m/s

Reach Truck width:

1120mm

Lift/drive motor power:

9-11kW (15kW High Seed Version)

Battery power:

48V / 310 – 620 Ah

R214

Model

R214

Capacity

1400kg/600mm

Operator:

Ride-on

Mast type:

Lift height:

4400mm

Max lift height:

6300mm

Travel speed loaded/unloaded:

10/11.2km/h

Lifting speed loaded/unloaded:

0.27/0.42 m/s

Lowering speed loaded/unloaded

0.50/0.44 m/s

Pallet Truck width:

1120mm

Lift/drive motor power:

9-11kW (15kW High Seed Version)

Battery power:

48V / 310 – 620 Ah

R216

Model

R216

Capacity

1600kg/600mm

Operator:

Ride-on

Mast type:

Lift height:

4400mm

Max lift height:

8500mm

Travel speed loaded/unloaded:

10/11.2km/h

Lifting speed loaded/unloaded:

0.25/0.42 m/s

Lowering speed loaded/unloaded

0.50/0.44 m/s

Pallet Truck width:

1120mm

Lift/drive motor power:

9-11kW (15kW High Seed Version)

Battery power:

48V / 310 – 620 Ah

* Mast Type: Duplex Tele (DT), Duplex Freelift (DF), Triplex Freelift (TF)
